XL Specialized 80 HDGS – Lowboy, 48' x 102", 80,000 lbs Distributed
XL Specialized 80 HDGS Lowboy with an overall length of 48' and capacity 80,000 lbs Distributed.
Key Specs
- Overall Length: 48'
- Overall Width: 102"
- Capacity: 80,000 lbs Distributed
Gooseneck
- Neck Style: Low-Profile Scraper
- Length: 11'
- Kingpin Setting: 16"
- Swing Clearance: 86"
- Fifth Wheel Height: 51" with 5 Variable Ride Height Positions
- Hydraulics: 13 HP Honda, Dual Hydraulics, Steel Cover (Base of Gooseneck)
Main Deck
- Length: 28'
- Loaded Deck Height: 18"
- Ground Clearance: 6"
- Decking: 1 1/8" Apitong Decking, Full-Width Style
- Beams: (4) 12" Fabricated I-Beams
- Crossmembers: 6" & 4" JR I-Beam on 12" Alternating Centers
- D-Rings: (8) Bent D-Rings Per Side, (4) Pan-Style D-Rings Per Side
- Outriggers: Removable Swing-Out Outriggers, Brackets Only on 24" Centers
- Ramps: Tapers to 4"
- Chain Drops: 24" Centers - Outside Beams
Rear Deck
- Length: 9'
- Loaded Deck Height: 40"
Axles & Suspension
- Axles: (2) 25,000 lbs Nominal (5/8" Wall)
- Suspension: Hendrickson Air Ride, 25,000 lb Capacity
- Axle Spacing: 54"
- Brakes: 16 1/2" x 7" Drum Brakes, ABS 4S2M with Spring Brakes on (2) Axles
Wheels & Tires
- Tires: 255/70R 22.5 (H)
- Wheels: 8.25 x 22.5, 10-Hole Pilot Mount, Steel Disc Inner/Polished Aluminum Outer
Lighting & Safety
- Electrical: 12V Sealed Grote System with (3) Tail Lights
- Strobe Lights: 4" Amber Strobe Light with Switch
Additional Features
- Paint: Black
- Ride Height Control: Manual Ride Height Control, Raise and Lower Valve
- Flip Axle Preparation: Prepped for Flip Axle
- Clearance Lights: (4) Extra Pairs on the Main Deck
- Flag Holders: (2) Pairs EZ Mount Flag Holders
- Monitoring: Liquid Filled Air Gauge
- Rear Transition Cutout: 2' x 2'
