Dorsey DC53 Trailer

Dorsey DC53 – Lowboy, 53' Overall Length, 80,000 GVWR

Dorsey DC53 lowboy, 53' overall length and 80,000 GVWR.

Key Specs

• Type: DC-22.5 DROP DECK COMBO FLATBED
• Capacity: STANDARD BEAM PKG – 80,000 GVWR (60,000 IN 10' SPAN)
• Overall Length: 53'
• Overall Width: 8' 6"
• Base Weight: 11,680#
• Paint: BLACK

Tub Construction

• Main Frame: 26" FAB. - PRE CAMB I-BEAMS (80K PKG)
• Side Rails: 6" - ALUM-EXTRUDED W/ DOUBLE L TRACK
• Top Deck Length/Height: 10' 6" LENGTH = 59" HEIGHT
• Lower Deck Length/Heights: 42' 6" LENGTH = FRONT 41', CENTER 42, REAR 40" HEIGHTS
• Top Deck Floor Sills: 4" STEEL I-BEAM 18" O.C. HD PKG. (+325#)
• Lower Deck Floor Sills: 4" STEEL I-BEAM 12" O.C. HD PKG
• Floor Decking: 1-1/8" HD ALUMINUM W/ 2 NAILER BOARDS
• Front Skirt: ALUMINUM FRONT AND CORNERS
• Rear Skirt: ALUMINUM
• Bulkhead: NONE
• Rub Band Alum: 3/8" x 3" - ALUMINUM – RECESSED FOR DOT TAPE

Axles & Suspension

• Suspension: AIR RIDE – HENDRICKSON INTRAAX-25K 2 AXLES
• Suspension Location: R.A.S. CAL LEGAL (CENTER OF KP TO CENTER OF REAR AXLE 40' IN CLOSED POSITION)
• Axles: (2) 25K CAPACITY – TYPE 30 CHAMBERS – AUTO SLACKS – ABS – 22.5 TIRES (1463#)
• Axle Spacing: RAS – 2 POSITION – 49" & 10' 2" SPREAD
• Lift Axle: NONE
• Parking Brakes: ALL AXLES
• ABS System: WABCO ABS SYSTEM 2S/1M
• Dust Shields: NONE

Wheels & Tires

• Wheels: DISC – HUB PILOTED – 22.5 STEEL (672#)
• Tires: 255/70R 22.5 - FIRESTONE
• Tire Inflation System: NONE
• Tire Carriers: TIRE CARRIER POSITIONED IN FRONT OF MAIN BEAMS BETWEEN LANDING GEAR

Additional Features

• Winches: 12 DOUBLE L (+) #75
• Winch Track: DOUBLE L ALUMINUM – EXTRUDED SIDERAIL C/S & R/S - BOTH SIDES
• Tie Bar: D/S & C/S - FULL LENGTH NOTH SIDES – 3/8" x 2"
• Straps: NONE
• Landing Gear: TWO SPEED
• Coil Haul Package: SINGLE COIL PLACEMENT – 5 EXTRA STUD SILLS-CTR ON TRAILER
• Stake Pockets: 24" O.C. SIDES & ACROSS REAR
• Spool: TRIANGULAR SHAPED
• Dock Bumpers: RUBBER INBOARD
• Cargo Tie Down: 14 PAIR OF RECESSED CHAIN TIES EVENLY SPACED
• Container Twist Locks: NONE
• Dunnage Rack: ALUMINUM DUNNAGE RACK DRIVERS SIDE – 8' 3"
• Toolbox Material: ALUMINUM – SMOOTH BOX 18Hx18Dx60L – CAM LOCK
• Toolbox Location: DRIVER SIDE – BEHIND LANDING GEAR
• Anti-Sail Mud Flaps: BEHIND ALL AXLES
• Scales: NONE

Lighting & Safety

• Lights: GROTE ULTRA BLUE SEALED WIRING HARNESS – 2 MICROS PER SIDE & MID TURN – 3/3/3 REAR
• Custom Lights: NONE
• Dump Valve: ELECTRIC WIRED THRU AUX 7WAY PLUG @ FRONT OF TRAILER – DUMP REAR AXLE (+9#)
