2024 Retesa Guppy, Retesa. HCC-1EM-H4100 Gupp · Unit RT-51

Retesa Guppy, Retesa. HCC-1EM-H4100 – Guppy, 4100 cu ft, 52' OAL

Retesa Guppy, Retesa. HCC-1EM-H4100 is a pneumatic dry bulk tanker trailer with 4100 cu ft capacity and 52' OAL.

Key Specs

• Manufacturer: Retesa
• Model: HCC-1EM-H4100 Guppy
• Capacity: 4100 cu ft
• Length: 52' OAL
• Purpose: Store dry goods, cement powder and more.
• Estimated weight: 26,455#
• Hoppers: (6)
• Hopper slope: 45 degree

Tub Construction

• Manhole: (1) 20" full operating manhole offset to roadside near center
• Bottom aeration: bottom aeration w/ 30" fabric air pads
• Individual hopper aeration control: individual hopper control of air supply to aeration w/ check valves
• Paint: Painted Haliburton Grey.

Hydraulics & Control

• Discharge lines: 5" discharge lines terminated with 6" butterfly valves
• Discharge valves & line: 6" discharge valves x 5" discharge line roadside ahead of axle
• Loading lines: (2) 4" loading lines (1) front and (1) rear
• Air supply line: 4" air supply line curbside front
• Blowdown line: 3" blowdown line at rear
• Gauges: gauges at roadside front (1) each tank and line gauge
• Motor/blower packages: Diesel and Electric Motor and Blower Packages available

Axles & Suspension

• Suspension: single axle Reyco 88 spring suspension w/ air brakes

Wheels & Tires

• Tires & wheels: 11R 22.5 tires on steel disc wheels

Additional Features

• Jackscrews: (10) jackscrews
• Lighting: LED lights
