2022 Xl Specialized 80 HDE. XL Spec. Lowboy Lowboy · Unit RT-04

Xl Specialized 80 HDE. XL Spec. Lowboy – Lowboys, 54' 6" x 102"

Xl Specialized 80 HDE. XL Spec. Lowboy – Lowboys with 54' 6" overall length and 102" overall width.

Key Specs

• Overall Length: 54' 6"
• Overall width: 102"
• Capacity: 80,000 LB Distributed; 60,000 LB 10' Closed
• Weight: +/- 3% 0,00 LB
• Kingpin Setting: 16"
• Swing Clearance: 86"
• 5th Wheel Height: 51" W/5 Variable Ride Height Positions

Tub Construction

• Gooseneck Length: 11' Full Width Neck
• Neck Style: Scraper
• Decking: 1 1/8 Apitong Decking, Flush, Center covered
• Main Deck Length: 29" / Opening to 50" 11" Mini Deck
• Main Loaded Deck Height: 20' W//6" Ground Clearance
• Crossmember: 4" JR. I-Beam and knee braces on 12" Alternating Centers
• Side Beams: Fabricated I Beam
• Rear Deck Length: 16' 6" - 2' x 2' Cutout in rear transition
• Rear Loaded Deck Height: 40"
• D-Rings (main): 8 Bent D-Rings per Side
• Outriggers: Removable swingout outrigger brackets only on 24" Centers
• Chain Drops: Chain Drops on 24" Centers
• Ramps: Tapers to 4"

Hydraulics & Control

• Hydraulics: 13HP Honda power unit, hual hydraulics, steel cover, electric hook ups at both standard location and base of neck
• Flip Neck Prep: Prep for 36" flip neck extension
• Flip Neck Extension: 36" Flip Neck extension
• Manual Ride Height Control: Manual Ride Height Control
• Air Lift: Air Lift On Rear Axle
• Raise/Lower Valve: Raise And Lower Valve

Axles & Suspension

• Axles: (3) 25,000 Nominal, 77 1/2" Tracking
• Suspension: Ridewell/25,000 Air
• Axle Spacing: 60"
• ABS: 4S2M Spring Brakes on 2Axles
• Brakes: DISC

Wheels & Tires

• Tires: 255 / 70R / 22.5
• Wheels: 8.2 X 25.5 Steel Inside, Aluminum Polished Outside, Disk

Electrical

• Electrical: 12V sealed grote system with 2 tail light aluminum package
• Electric hook ups: at both standard location and base of neck

Additional Features

• D-Rings (tail): 2 pair of pan style D-Ring- one in each corner - 2 stake pockets in tail channel
• Flag Holders: 2 Pair Flag Holders
• Pull Out Lights: 2 Pair Pull Out Lights - One at front and one at rear (Extension stops on 24" centers)
• Tool Box: Tool Box in rear of main deck - Mini Deck
• Clearance Lights: 7 Clearance Lights Per Side On Main Deck
• Scale: Air Weight Digital Scale
