SMITHCO SX3 THREE-AXLE SIDE DUMP

DIMENSIONS:

• 41' 4" Frame Length
• 102" Width
• 18" Kingpin Setting

FEATURES:

• Electric Tarp System
• Bolt-on Push Block
• LEDS Lights

FRAME & TUB:

• High Tensile Tapered Frame
• AR400 Steel Construction
• Tailer Mounted Electric-Over Hydraulic Valve
• Front & Rear Fenders
• 34' Length Tub - Round Bottom
• 23 Cubic Yard Capacity - Level Full
• 31 Cubic Yard Capacity - Heaped
• Low Slung Center Stabilizer/Divider
• Water Tight Tub w/Drain Plugs

UNDERCARRIAGE:

• Neway RL250 Air Ride Suspension
• Air Lift 3rd Axle
• (3) 25,000#, 77 1/2" Wide Trac Axles
• Outboard Hubs / Cast Drums
• Oil Bath Hubs
• Anti-Lock Braking System - 2S1M
• Hub Piloted Wheels
• (6) 12.5 x 22.5 Aluminum Wheels
• (6) 385/65R22.5 Yokohama RY253 Radial Tires
