SmithCo SX6-53-40 Trailer

SmithCo SX6-53-40 – Side Dump, 53' frame, 40' tub

SmithCo SX6-53-40 side dump with 53' frame and 40' tub; SX-ROUND BOTTOM tub with 3/16" AR450 sides and floor.

Key Specs

• Manufacturer: SmithCo
• Model: SX6U
• Frame Width: 102" WIDE
• Frame Length: 53'
• Tub Length: 40'
• Tub Volume: 40' SX - WATER LEVEL - 26.8 CUBIC YARDS; 40' SX - HEAPED - 35.6 CUBIC YARDS

Tub Construction

• Tub Style: SX-ROUND BOTTOM
• Tub Sides: 3/16" AR450
• Tub Floor: 3/16" AR450
• Tub Dividers: 0
• Tub Paint #: DV-19088 (WHITE)

Hydraulics & Control

• Hydraulics: 6" CYLINDERS
• Valve on Trailer: HYDRAULIC CONTROL VALVE ON TRAILER (ELECTRIC/HYDRAULIC)
• Dolly Legs: MARK V
• Grease Bank: FOR HYDRAULIC CYLINDERS FRONT AND REAR - STD
• Lock Out Switch: TARP LOCKOUT
• W Style Pushblock: STD
• Large Air Gauge: LARGE LIQUID FILLED AIR GAUGE ON DRIVER'S SIDE - STD

Axles & Suspension

• Suspension: RIDEWELL RW260 AIR RIDE
• Axle Spacing: 52"-52"-62"-62"-64"
• Lift Axle: 1ST, 2ND & 6TH (13.2 HD) ALL STEERABLE LIFTS ON SEPARATE SWITCHES
• ABS Axles: 25K 1
• Non-ABS Axles: 25K 5
• Axle Track: 83.5"
• Hubs: DURALITE-STD
• Brakes: 16-1/2"x7"
• Drums: CAST STEEL ZERO OFFSET WHEELS ON SUPER SINGLES

Wheels & Tires

• Wheel Style: HUB-PILOTED U/M
• Wheel Type: AL SS 12.25x22.5 6 SUPER SINGLE ALUM ON 3-5, (6) STD ALUM ON 1,2 & 6
• Tires: DC RLB980 385/65R22.5 6 385/65R22.5 ON 3-5, (6) 275/70R22.5 ON 1,2 & 6
• Fenders: ALL PLASTIC

Additional Features

• Tarp Brand: AERO
• Tarp Type: MESH-NON SEALED

Lighting & Safety

• Tail Lights: 3 TAILLIGHTS - RED
• ID Lights: 5 ID LIGHTS AT REAR
